WILLIAM R. BENNETT BRIDGE

Location:

Kelowna, BC



Owner:

BC Ministry of Transportation



Client:

WRB Group (SNC Lavalin Inc. & VPDL

Joint Venture)



Contract Value:

$40M



Type of contract:



Start Date:



Completion Date:

August 2010









The William R. Bennett (WRB) Bridge is a two kilometre
corridor that straddles Okanagan Lake to connect two communities, Kelowna and West Kelowna.

The William R. Bennett (WRB) Bridge is a two kilometre corridor that straddles Okanagan Lake to connect two communities, Kelowna and West Kelowna.

Acting as both a member of the design build joint venture and dedicated subcontractor, Vancouver Pile Driving led the marine construction including the construction of a 30 m wide by 100 m long by 7m deep Graving Dock (Drydock) using sheet piles on the Shore of Okanagan Lake for fabricating the floating concrete pontoons. Vancouver Pile Driving also supplied and installed 89 piles at 2 abutments and 5 piers

  • The original design of the bridge had shorter sized floating concrete segments; however, after re-design and upon further geotechnical investigation of the area, the graving dock was increased in size to minimize the number of concrete segments and reduce the number of connections. Additionally, during the construction of the graving dock, discovered archeological artifacts led to a shutdown of three months while investigations took place. The team was able to overcome the delays and complete the construction ahead of schedule.
  • The demolition and disposal of the floating sections of the existing floating bridge was challenging. It was concluded that the best option was the demolition and recycling of the pontoons within the graving dock facility. The final disposal saw the steel recycled and the concrete was reclaimed by crushing it and the transporting it for road case on other highway construction projects.
  • Design-build contract $125M
  • Interaction with local first nations
  • Multi-year project
  • Working in deep water
  • Significant marine spread of footprint
