DELTA PORT BERTH 3 EXPANSION

Location:

Delta, BC



Owner:

Port Metro Vancouver



Client:



Deltaport Constructors (Graham &

VanPile JV)



Contract Value:

$200M



Type of contract:



Start Date:

2006



Completion Date:

2009



Successfully adding a third berth to Canada’s biggest and busiest container terminal, three months ahead of schedule.

The development of the project was an initiative to expand the container capacity at the port to accommodate consumer and business-driven demand for increased Canadian trade through the west coast of Canada. The development increased capacity at Deltaport by approximately 600,000 TEUs by adding a third berth and 20 hectares of container storage facilities to the existing two-berth container terminal.

  • The 432 lineal meter berth was constructed using 10 sunken concrete caissons, which were ballasted into place on a densified rock mattress.
  • The soil conditions at the Deltaport site consist of dense sands and silts, as this site is located near the mouth of the Fraser River. The berth design is a caisson quay wall wharf, which is the ideal structure for these soil conditions.
  • The caissons are large concrete boxes, designed to float, but need to be sunk on the seabed to create the quay wall. VanPile has a Graving Dock located in Vancouver Harbour that was used to fabricate the floating caissons.
  • The project also required approximately 500,000 cubic metres of dredging on the marine side and 1.5 million cubic metres of fills to create the upland component.
